Black 008A Mini Wireless Audio Tour Guide System Transmitter And
Receiver
TuMan 8 series device,apply to: wireless team
interpretation,simultaneous interpretation,etc.; Mainly used for
manned interpreatation: can manual use,also can play pre-recorded
audio,that need human to control. We have many models for your
choice!
Using graphic:
Applications:
Travel & Tourism: Tourism, museums, galleries, business and tour guides to explain
the convention;
VIP reception: The promotion of company's products, high-level exhibition, the
Government, the reception of VIPs visited the factory, industrial
tourism;
Teaching training: Schools, training institutes, conference rooms, auditorium,
classroom lectures, seminars and other learning activities, special
job training.
Simultaneous translation for multilingual meetings, seminars or
exhibitions
Radio aid system to assist hearing impaired people
They also can be applications for Guided tours of Museums, Public gatherings, sports ground and arenas, historical buildings
and art galleries - both indoors and outdoors. Noisy environments –
such as Factory and large plant tours
Descriptions:
TuMan 008A tour guide system is detrusion by HUMANTEK CO.,LTD,The
system adopts the international advanced wireless amplification
technology,to realize the function of intelligent voice explain.The
system related equipment light fashionable appearance,convenient to
carry.
Can be for the government officials and VIP customer
visits,conferences. more suitable for large companies,museums,theme
parks,scenic spots and historical sites,such as a tour by boat tour
guide use;
The dvice contains Transmitter and Receiver;
TuMan 008A product feature:
1.Many channels:dual channel 158 channels;
2.Far transmission distance:open field >= 200m;
3.The through wall effect is good:through concrete wall, brick wall
penetration effect;
4.The transmission effect to international level,the leading
domestic:Using core technology sound processing, perennial export
Europe and the United States and other countries!
Parameters:
| Name | Value |
| Working frequency: | 70.25-76.3MHz,794-806MHz,863-865MHz,902-915MHz,2.4GHz etc.,
Broadband, the sound quality is better; |
| Channel quantity: | 158(high frequency 100+Low frequency 58),
80,64,50 etc.,Different frequency different channel quantities; |
| Channel spacing: | 120KHz,200KHz,350KHz etc; |
| Transmitter power: | 10dBm,20dBm,30dBm etc; |
| Receiving sensitivity: | -110dBm(typical); |
| Working voltage: | 3.0-5.0VDC,recycle polymer lithium battery; |
| Input: | Input(Transmitter):3.5mm microphone; |
| Output: | Output(receiver):3.5mm headphone |
| Oscillator: | PLL; |
| Second harmonic trap: | >40dbc; |
| Frequency response: | 20Hz-18KHz; |
| Signal to Noise Ratio: | 80dB(typical); |
| Image reject: | >80dB; |
| Mirror harmonic: | >75dB; |
| Separation factor: | 70dB(typical); |
| Frequency offset: | <3k; |
| Distortion factor: | <1%; |
| Oscillation frequency: | +/-2ppm; |
| Working current: | Transmitter:≤30~80mA;Receiver:≤50mA; |
| Working distance: | >=250m; |
| Working temperature: | -20℃—+70℃; |
| Dimensions: | Length65mm×Width50mm×Height17mm; |
| Weight: | 50g(battery included); |
How to get:
Business Process:Tell us your basic needs—>Solutions and
Quotes—>Signing the Agreement—>Payment
—>Shipments—>ReceiveExamine goods—>After Sales;
Contact Us:Pleas click CONTACT US ,Or to the Footer,Call or E-Mail
to us,Thank you!
Inquiry Consulting: INQURIY (Free):
longen.generatorM.P:+86-183-55187022(WhatsApp)
Part of Accessories:
Earphone(EP01)) |
Micphone(Mic01) |
| |
Earphone(EP02)) |
Micphone(Mic02) |
| |
Charing box 1 for 30(Model:6BoxC01) |
Charger 1 for 10(Model:UCG01) |
